NT-URS Universal Remote Sensor

The Network Thermostat NT-URS universal remote sensor is a surface mount remote sensor in a small case, designed to sense air temperature and/or humidity at remote locations when connected to a X7, X5, or UP32 thermostat, or temperature on an US32 Thermostat.

The flexible NT-URS sensor can be used in several configurations including indoor temperature and humidity, humidity only, outdoor temperature, or as any of three different auxiliary temperature sensor. Up to six (6) NT-URS sensors can be connected to a single thermostat for indoor temperature averaging.

While both temperature and humidity features are available on the X7, X5 and UP32 thermostat families, only the indoor and outdoor temperature features are integrated into the US32 thermostat.

Supports the Following Sensing Types:

Specifications

• Multiple Configurations for Flexible Application Use
• Six (6) Can Be Used as INDOOR Sensors For Automatic Room Temperature Averaging
• Measurement Ranges with Sensor Types:
• INDOOR +28°F to +119°F (-2°C to +48°C)
• OUTDOOR -54°F to +119°F (-48°C to +48°C)
• AUX1, AUX2, AUX3 -40°F to +200°F (-40°C to +48°C)
• HUMIDITY 5 to 95% Non-Condensing
• Simple 3-Wire Communications Bus (using standard CAT5 cable, 1-pair shielded with drain, 3-conductor thermostat cable)
• Maximum 300ft Total Sensor Cable Length per Thermostat
• Selectable Fahrenheit or Celsius Display on Thermostat
